A1-20 SS Automatic Paper Towel Dispenser

Design Concept

The A1-20 SS Automatic Paper Towel Dispenser delivers essential hygiene and operational efficiency for high-traffic commercial environments, designed to meet rigorous demands. Its robust 304 stainless steel exterior and secure metal key-locked casing ensure a reliable service life exceeding five years, minimizing replacement costs for facility planners. Touchless operation, activated by an infrared sensor, guarantees a sanitary user experience, critical for public health protocols. This automatic Paper Towel Dispenser optimizes paper consumption with adjustable paper lengths of 20, 30, or 40 cm, directly reducing waste and lowering procurement expenditures. A transparent front viewing window provides maintenance staff with an immediate visual cue for paper levels, streamlining refill schedules to avoid service disruptions.

Materials & Craftsmanship

Constructed from high-grade 304 stainless steel with a fine brushed finish, the A1-20 Automatic Dispenser offers superior corrosion resistance, making it ideal for humid restroom environments common in commercial settings. This material choice ensures a service life exceeding five years and simplifies routine cleaning, reducing long-term maintenance expenditures for facility managers. The integrated metal keyed lock deters tampering and theft, securely protecting consumable paper towels. Internally, a high-quality cutting blade consistently delivers clean paper cuts, effectively accommodating various paper toughness levels without jamming, which is crucial for consistent performance in high-traffic facilities.

Functionality & User Experience

Designed for a completely touch-free experience, the A1-20 features an infrared sensor that automatically dispenses paper, promoting optimal hygiene in high-traffic public and commercial settings. Users benefit from two selectable working modes, including a 'tear-and-go' option, allowing facilities to customize dispensing to their specific traffic flow and paper usage needs. Its power-saving design supports an extended battery life when using 4 D-type (R20) 1.5V batteries for wireless installation flexibility, ideal for retrofitting existing facilities. For continuous power supply, the unit can be connected via an optional 220-240V/6V AC adapter (both not included), offering versatile installation options. A large viewing window enables easy monitoring of paper supply, ensuring continuous provision for end-users and efficient restocking by facility management.

Installation Options

The A1-20 stainless steel Paper Towel Dispenser is designed for straightforward wall-mounted installation, suitable for both new constructions and retrofitting existing washroom layouts. With compact dimensions of 347mm (W) x 227mm (D) x 386mm (H), it allows for flexible placement without requiring recessed wall space, simplifying project planning. Its robust backing facilitates secure mounting, ensuring stability and vandal resistance in high-traffic commercial settings, addressing facility security concerns. Professional installation is recommended to guarantee optimal functionality and long-term durability, adhering to local building codes and ADA guidelines, which is important for compliance-focused buyers.

1. Identify a suitable wall-mounted location away from direct water spray, adhering to local building codes and ADA guidelines.
2. Mark drilling points on the wall using the dispenser's backing plate as a template for precise placement.
3. Drill holes and insert appropriate wall anchors (not included), selecting based on your specific wall material for secure fastening.
4. Secure the dispenser’s backing to the wall using screws, ensuring it is level and firmly attached to withstand high usage.
5. Install 4 D-type (R20) 1.5V batteries or connect the optional 220-240V/6V AC adapter (both not included) to power the unit.
6. Load the non-perforated roll towel, ensuring it is correctly threaded through the internal cutting mechanism for proper dispensing.
7. Close the front cover and secure it with the provided metal key, then test the sensor and dispensing functionality to confirm operation.

Applications

This robust automatic dispenser is engineered for diverse high-volume commercial and institutional applications where hygiene, durability, and low maintenance are paramount. It is an ideal choice for high-traffic public restrooms in airports and convention centers, ensuring continuous service and guest satisfaction. Hospitals and healthcare facilities benefit from its touchless operation, contributing significantly to critical infection control protocols. Corporate offices and educational institutions can leverage its adjustable paper lengths to manage consumption and reduce operating costs, while restaurants and hospitality venues appreciate its sleek aesthetic and dependable performance for maintaining a clean environment.

Technical Specifications

The A1-20 automatic stainless steel Paper Towel Dispenser measures 347mm in width, 227mm in depth, and 386mm in height, providing a compact footprint for various installations. It is constructed from 304 stainless steel with a fine brushed finish, ensuring lasting durability and corrosion resistance. This unit accommodates non-perforated paper towel rolls up to 250mm in width and 210mm in diameter, offering flexibility in consumable choice. Power is supplied by either four R20 type D 1.5V batteries (not included) or an external 220-240V/6V AC adapter (not included), offering flexible energy solutions. Dispensing length is electronically adjustable to 20cm, 30cm, or 40cm, providing precise control over paper usage. Each unit is individually packaged in a carton sized 365 x 245 x 420mm, with a gross weight of 6.5kg.

About the Manufacturer

Shenzhen Pingdi AOLQ Bathroom Supply Co., Ltd, operating under the brands AOLQ, SBF, and WE, has been a trusted leader in commercial washroom solutions since its founding in 2002, offering over two decades of specialized expertise. Our 13,000m² state-of-the-art factory integrates design, R&D, manufacturing, and marketing, achieving a production capacity exceeding 10,000 units daily. We provide extensive OEM and ODM capabilities, specializing in high-quality 304 stainless steel products and plastic components with custom color options. Our commitment to quality, efficiency, and comprehensive service makes us an ideal partner for procurement managers and project buyers in North America, Europe, and the Middle East seeking reliable commercial washroom equipment.

Contact Us

For detailed specifications, customized solutions, or to discuss your bulk order requirements for the A1-20 SS Automatic Paper Towel Dispenser, please contact our export division today.
